12 Layer 3/3mil IC Test PCB Circuit

12 Layer 3/3mil IC Test PCB Circuit

Double-Sided PCB, 2-Layer PCB, Immersion Gold

Description

Basic Info
  • Model NO.: WBPN2245AO
  • Dielectric: FR-4
  • Flame Retardant Properties: V0
  • Processing Technology: Electrolytic Foil
  • Insulation Materials: Epoxy Resin
  • Brand: Xzg
  • Min Line Width and Distance: 3/3mil
  • Solder Mask Colour: Green
  • Trademark: XZG
  • Specification: IPC-Class 2
  • HS Code: 8534009000
  • Type: Rigid Circuit Board
  • Material: Fiberglass Epoxy
  • Mechanical Rigid: Rigid
  • Base Material: Copper
  • Model: PCB
  • Panel Size: 50*50mm
  • Min Hole Size: 0.2mm
  • Silkscreen Colour: White
  • Transport Package: Vaccume Package
  • Origin: Guangdong, China
Product Description

12 Layer 3/3mil IC Test PCB Circuit
Specification:
Layer   12
Material FR4-TG180
Board Thickness 2.0mm
Copper Thickness 1oz
Soldermask Green
Silkscreen White
Surface Finishing ENIG
Min Hole Size 0.2mm

Why US:
  • UL (E246887), ISO9001, TS16949, ISO 14001 certified.
  • Turnover USD 50-100 million per year
  • 25,000 sqm area,1100 staff
  • Mass Production from single to 20 layers
  • Special Material: ROGERS, Arlon, Taconic.etc.
  • Client: SAMSUNG, Skyworth, Malata, Midea.etc.

Capability & Lead Time:
12 Layer 3/3mil IC Test PCB Circuit


Certificates(UL:E246887, TS16949, ISO14001, ISO9001):
12 Layer 3/3mil IC Test PCB Circuit


Factory Tour:
12 Layer 3/3mil IC Test PCB Circuit
12 Layer 3/3mil IC Test PCB Circuit

Clients and Suppliers:
12 Layer 3/3mil IC Test PCB Circuit

FAQ:


Q1:Are you a manufacturer or trading company?
A:
XingZhiGuang is a PCB manufacturer, specialized in PCB for over ten years.


Q2:What kind of PCB file you need before production

A:Gerber, or files like PROTEL 99SE, PROTEL DXP, POWER PCB, CAM350.etc.
b. Dimensional Specifications
c. BOM List (only for PCBA)

Q3: How long will you send us quotation ?
A: After all files were sent, 2 to 8 hours as per your file.



Q4:What is your minimum order quantity?

A:Our MOQ is 1 PCS.


Q5: How to find you?
A: Please click the button "send" at the end of each page, or contact our sales on Trade Manage online!
